🧱 Footing Kya Hoti Hai? | Ghar Ki Foundation Ka Pehla Kadam
Ghar ki mazbooti hamesha neeche se shuru hoti hai, aur uska pehla kadam hota hai — Footing.
Footing wahi jagah hoti hai jahan se poore ghar ka load zamin tak transfer hota hai. Agar footing sahi design aur execution se banai gayi ho, to ghar saalon tak safe aur durable rehta hai.
🧩 Footing Drawing Kaise Padhe?
Aapko kaise pata chalega ki aapke ghar ki footing strong ban rahi hai ya nahi?
Aur architect aur engineer ne jo drawing di hai, kya wahi site par implement ho rahi hai?
Chaliye samjhte hain footing drawing ka structure:
1️⃣ Column Numbers:
Har column ka apna footing number hota hai.
Example: C1, C2, C3 – jitne column utne footing.
2️⃣ Footing Size:
Drawing me likha hota hai jaise 5’x5’, 6’x6’, 6.6’x6.6’.
Size depend karta hai column ke load par.
👉 Jitna bada column, utni heavy footing.
3️⃣ PCC (Plain Cement Concrete):
PCC base usually 100mm-150mm thick hota hai, ratio 1:4:8 (Cement: Sand: Aggregate).
Ye footing ke neeche ek level aur clean surface deta hai.
4️⃣ Reinforcement Details:
Footing drawing me likha hota hai — jaise “10mm @150mm c/c both ways”.
Matlab 10mm ke bars dono direction me 6 inch distance par dale jaayenge.
5️⃣ Thickness (t & T):
“t” aur “T” footing ke step thickness ko dikhate hain —
- t = First step thickness
- T = Second step thickness
Stepped footing me ye bahut important hota hai.
6️⃣ Cover Distance:
Footing me generally 50mm cover rakha jata hai steel ko corrosion se bachane ke liye.
7️⃣ Footing Level:
Drawing me “PCC at -1200mm” ya “Footing top -1050mm” likha hota hai,
iska matlab footing kitni depth pe cast karni hai.
🏗️ Footing Ke Pramukh Prakar (Types of Footing)
1️⃣ Isolated Footing:
Har ek column ke neeche alag footing — sabse common gharon me.
2️⃣ Combined Footing:
Jab do columns ke beech ka distance kam ho, dono ke liye combined footing banayi jati hai.
3️⃣ Stepped Footing:
Jab soil bearing capacity (SBC) kam ho, aur load zyada, to step form me banai jati hai — jisse load evenly distribute ho.
4️⃣ Raft / Mat Footing:
Jab poore plot me load spread karna ho — basement ya weak soil wale area me.
5️⃣ Pile Foundation:
Jab soil bohot soft ho, aur load deep strata tak le jaana ho — to pile footing use hoti hai (generally for high-rise).
📏 Tentative Footing Size for Residential Homes (Normal SBC Soil – 15 to 20 T/m²)
| Structure Type | Typical Column Size | Tentative Footing Size | Depth (Approx.) |
|---|---|---|---|
| Ground + 1 (G+1) | 9”x9” to 9”x12” | 5’x5’ to 6’x6’ | 1.2m to 1.5m |
| Ground + 2 (G+2) | 9”x12” to 12”x12” | 6.6’x6.6’ to 7’x7’ | 1.5m to 1.8m |
| Ground + 3 (G+3) | 12”x12” to 12”x15” | 7’x7’ to 8’x8’ | 1.8m to 2.0m |
⚠️ Ye approximate values hain — actual footing size soil test aur structural design par depend karega.
🧾 Footing Shuru Karne Se Pehle Kya Check Karna Chahiye
1️⃣ Soil Compaction:
PCC dalne se pehle soil ko proper compact karein.
Loose soil foundation ko weak bana deti hai.
2️⃣ Layout & Center Line:
Architect ke layout ke hisab se column center line match karein.
3️⃣ Footing Level & Depth:
Har footing ka level ek hi line me ho, uneven na ho.
4️⃣ Reinforcement Placement:
Bars properly tied ho, cover blocks sahi jagah lagaye ho.
5️⃣ Formwork Stability:
Side shuttering firm aur leak-proof ho.
6️⃣ Concrete Quality Check:
Cement fresh ho, ratio aur mixing sahi ho, slump test pass ho.
⚙️ Concrete Ratio for Footing
Usually M20 Grade Concrete (1:1.5:3) use hota hai.
Isme 1 part Cement, 1.5 part Sand aur 3 part Aggregate hota hai.
Water-cement ratio around 0.45–0.50 rakha jata hai.
PCC (Plain Concrete) ke liye: 1:4:8 ya 1:3:6
RCC Footing ke liye: M20 (1:1.5:3) minimum.
🔩 Minimum Steel in Footing
As per IS 456:2000:
- Minimum reinforcement area = 0.12% of total cross-sectional area (for Fe415 steel).
- Generally 10mm or 12mm bars dono direction me lagaye jaate hain.
- Bar spacing: 150mm c/c (6 inch) common residential construction me.
- Lap & bend anchorage properly follow karein.
⚠️ Common Mistakes to Avoid
🚫 PCC compact na karna
🚫 Bar spacing follow na karna
🚫 Column starter bars galat jagah
🚫 Concrete cover kam rakhna
🚫 Weak shuttering or honeycomb concrete
🏡 Conclusion
Ek strong ghar ki shuruaat hamesha ek strong footing se hoti hai.
Agar footing sahi design, sahi concrete, aur sahi execution ke sath banai gayi ho,
to ghar saalon tak safe, durable aur crack-free rehta hai.
